SV-G2055KP (20-55 kgf.cm ; Push-to-start) Vector Vina Brushless Electric Screwdriver

Name: SV-G2055KP (20-55 kgf.cm ; Push-to-start) Vector Vina Brushless Electric Screwdriver
Brand: Vector Vina - Electric Screwdriver - Vector Electric Screwdriver
SKU: SV-G2055KP
Price: 1 VND
Availability: InStock

SKU: SV-G2055KP

The Vector Vina SV-G2055KP is a premium brushless electric screwdriver featuring a powerful torque range of 20 – 55 kgf.cm. The tool uses a Push-to-start mechanism specialized for vertical assembly operations. Combined with precision clutch technology (±5% accuracy) and an advanced optical brake, the SV-G2055KP delivers stability, durability, and maximum productivity optimization for industrial assembly lines.

Chat Zalo 0969 56 56 80

Sales Leader: 0366 139 169 Sales Exec: 087 86 000 86

VECTOR VINA SV-G2055KP

Industrial Brushless Electric Screwdriver Series – High Torque

Equipment Overview

The SV-G2055KP is the highest-torque model in the SV-G Series ecosystem, specifically engineered for fastening applications requiring high torque and superior stability. Equipped with an advanced brushless motor, the tool operates durably without heat generation, significantly extending its service life. The push-to-start design enables rapid operation, reduces redundant movements, and is particularly optimized for vertical assembly positions on industrial production lines.

Core Technology Features

Brushless Motor

High-efficiency brushless motor technology ensures quiet operation, low vibration, and completely eliminates periodic carbon brush replacement.

Precision Clutch

An optimally designed clutch mechanism maintains stable torque accuracy within ±5%, ensuring consistent quality across every screw joint.

Optical Brake

Replaces traditional mechanical brake switches with a photoelectric sensor, eliminating technical latency and extending the lifespan of the control system.

Ergonomic Design

A slim body with a premium non-slip plastic housing, combined with a push-to-start mechanism, significantly reduces wrist strain for the operator.

Detailed Technical Specifications

Technical Specification	Model SV-G2055KP
Torque (kgf.cm)	20 – 55
Torque (N.m)	1.96 – 5.39
No-load Speed (rpm)	500
Machine Screw	4.0 – 5.0 mm
Tapping Screw	3.0 – 4.0 mm
Start Type	Push-to-Start (Push)
Operating Voltage	DC 36V
Bit Shank Size	Hex 6.35 mm (1/4″)
Weight / Length	620g / 260mm
