VECTOR SVA-L30180B Right-Angle Pneumatic Screwdriver (Auto Shut-Off, 30-180 Kgf.cm)

SKU: SVA-L30180B

⚙️ KEY FEATURES OF VECTOR SVA-L30180B

Design: Right-angle L-type design – Ideal for tight spaces and recessed machine areas.
Mechanism: Pneumatic auto shut-off – Ensures high torque accuracy (±3%).
Torque: 30 ~ 180 Kgf.cm (High fastening torque for large screws M5.1 – M9.3).
Speed / Weight: 300 rpm / Weight 1.2 kg, stable and solid operation.
Air Requirements: Standard pressure 6.0 Kg/cm², 6.35mm hex bit holder.

Chat Zalo 0969 56 56 80

Sales Leader: 0366 139 169 Sales Exec: 087 86 000 86

1. Overview of Angle Pneumatic Screwdriver VECTOR SVA-L30180B

In machinery, automotive, motorcycle, or HVAC assembly lines, operators frequently encounter fasteners located in blind spots or undercarriages that standard straight screwdrivers cannot reach. The VECTOR SVA-L30180B pneumatic screwdriver with its right-angle head design (L-type) is the ideal solution for this challenge.

Powered entirely by compressed air, the tool integrates a highly responsive auto shut-off clutch mechanism. The SVA-L30180B is a high-power version delivering a torque range from 30 to 180 Kgf.cm at a speed of 300 rpm, ensuring accurate fastening of large screws (M5 – M9) without thread damage.

2. KEY TECHNOLOGICAL FEATURES

📐

Ergonomic Right-Angle (L-Type) Design

The driving head is angled at 90 degrees to the tool body. This lever-style geometry not only allows access into tight spaces but also provides better wrist leverage when fastening at high torque up to 180 Kgf.cm.

🛑

Precision Auto Shut-Off Mechanism

High-grade clutch assembly with an accuracy tolerance of just ±3%. Once the preset torque is reached, the air supply is automatically cut off and the tool stops immediately, providing optimal thread protection.

💪

Durable Industrial Air Motor

Carbon brush-free operation with no high heat generation. Capable of continuous 3-shift operation in harsh industrial environments while maintaining absolute stability.

🛡️

Solid Body with Anti-Slip Grip

A well-balanced 1.2kg weight helps absorb vibration and reduce kickback on the operator's hand. The handle is coated with soft rubber/elastomer for a secure grip even in oily conditions.

3. DETAILED TECHNICAL SPECIFICATIONS TABLE

* Comparison of SVA-L30180B specifications with other high-torque models in VECTOR's L-Type series.

Model	Torque (Kgf.cm)	Speed (rpm)	Screw Size (Machine Screw)	Weight (g)	Length (mm)	Bit Drive (Bit Type)	Air Consumption (m3/min)
SVA-L765B	7 – 65	1000	M2.9 – M6.4	1200	235	6.35 mm	0.55
SVA-L1595B	15 – 95	550	M4.1 – M7.0	1200	235	6.35 mm	0.55
SVA-L30180B	30 – 180	300	M5.1 – M9.3	1200	235	6.35 mm	0.55
SVA-L50250B	50 – 250	250	M6.0 – M11	1200	235	6.35 mm	0.55
